Copy of LY4N-J DC110/240 BY OMI Standard type/Single stable, Single, Plug-in terminal, Not equipped, 24 VDC 10 A, 110 VAC 10 A, Output 4PDT (24 VDC 10 A)

Product variants

Quantity

Coil ratings	24 VDC 69 mA
Contact form	4PDT
Contact method	Single
Contact material	Ag alloy
Contact rated load	110 VAC 10 A (Resistive load) 110 VAC 7.5 A (Inductive load (cosφ = 0.4)) 24 VDC 10 A (Resistive load) 24 VDC 5 A (Inductive load (L/R = 7 ms))
Terminal structure	Plug-in terminal

**Ratings**
Degree of protection		Closed type (cover)
Terminal structure		Plug-in terminal
Coil	Coil ratings	24 VDC 69 mA
	Coil resistance	350 Ω
	Operate voltage (Set voltage)	80% max.
	Release voltage (Reset voltage)	10% min.
	Maximum voltage	110%
	Power consumption	Approx. 1.5 W
Contact	Contact rated load	110 VAC 10 A (Resistive load) 110 VAC 7.5 A (Inductive load (cosφ = 0.4)) 24 VDC 10 A (Resistive load) 24 VDC 5 A (Inductive load (L/R = 7 ms))
	Max. contact voltage	250 VAC 125 VDC
	Max. contact current	AC: 10 A DC: 10 A
	Contact form	4PDT
	Contact method	Single
	Contact material	Ag alloy
